Porturi:
8
Standarde:
IEEE802.3, 802.3u, 802.3ab, 802.3x CSMA/CD, TCP/IP
Cu Management
NU
Conectivitate:
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
1000Base-T: UTP category 5, 5e cable (maximum 100m)
LED Indicators
Power, Link/Act (1000Mbps, 10/100Mbps)
Securitate:
Safety & Emission FCC, CE
Tabela de adrese MAC
8k
Viteza de transfer:
Backbound Bandwidth 16Gbps
Forwarding Rate :
10BASE-T: 14880pps/port
100BASE-TX: 148800pps/port
1000BASE-T: 1488000pps/port
Caracteristici speciale:
Basic Function :
Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and backpressure for Half-Duplex Mode
Altele:
Transmission Method Store-and-Forward
Alimentare (V/Hz)
100-240VAC, 50/60Hz
Dimensiuni (W x D x H mm):
250 x 158x 44 mm
