Switch 8 porturi PoE+, 2 porturi uplink - HIKVISION DS-3E0310HP-E

Switch-ul PoE DS-3E0310HP-E este un echipament special conceput pentru sisteme de supraveghere IP, ce permite transferul de date cu viteze de 10/100/1000 Mbps si dispune de 8 porturi PoE+ si 2 porturi de uplink.



Cele 8 porturi PoE RJ45 suporta auto-negotiation si poate telealimenta echipamente Ethernet (functie PoE) pana la o distanta de 250m in mod CCTV.

DS-3E0310HP-E este echipat cu 2 porturi de uplink 10/100/1000 Mbs - 1 port pentru NVR si un port pentru conectare la router iar porturile PoE comunica doar cu porturile de uplink.



Switch-ul dispune de o putere totala PoE de 110W (13.7W/port dar nu mai mult de maxim 60W/port1). Protectie ridicata la descarcari electrice, anti-interferente si tensiune electrostatica.

Producator: HIKVISION
Numar porturi PoE: 8 porturi RJ45 10/100Mbs
Putere PoE: 110W - (13.75W/port) 30W max/port 1-8 60W max port 1
Porturi Uplink: 2 porturi RJ45 10/100/1000Mps
Mod functionare: Standard (100m) / CCTV (250m)
Protectie: ESD descarcari electrice anti-interferente
Tensiune alimentare: 48 VDC 2.5 A (alimentator inclus)
Temperatura operare: -0 ~ +40 C
Dimensiuni: 217.6 mm 27.8 mm 103.35 mm
Greutate: 550 gr.
Consum: <120W (inclusiv PoE)

De la Bocris poti cumpara online Hikvision UNMANAGED NETWORK SWITCH 8X POE PORTS DS-3E0310HP-E la pretul de 398,44 lei, precum si alte Switch-uri ieftine.

Hikvision DS-3E0310HP-E

Hikvision unmanaged network switch, DS-3E0310HP-E; 1 10/100 Mbps HiPoE port, 7 10/100 Mbps PoE ports, and 2 10/100/1000 Mbps RJ45 ports; IEEE 802.3at/af/bt standard for HiPoE port (Max. 60W port power), IEEE 802.3at/af for PoE ports, IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, and IEEE 802.3z; PoE port with 6KV surge protection; AF/AT camera can reach up to 250m in extend mode; HiPoE camera can reach up to 150m; 120W, 48VDC, 2.5A;
