Putere (VA):
450
Montabile in rack:
Da
Intrari:
Nominal Input Voltage 230V,Input Frequency 50/60 Hz +/- 3 Hz (auto sensing),Input Connections IEC-320 C14,Input voltage range for main operations 160 - 286V,Input voltage adjustable range for mains operation 151 - 302V
Iesiri:
Output Power Capacity 280 Watts / 450 VA,Max Configurable Power 280 Watts / 450 VA,Nominal Output Voltage 230V,Output Voltage Distortion Less than 5% at full load,Output Frequency (sync to mains) 47 - 53 Hz for 50 Hz nominal,57 - 63 Hz for 60 Hz nominal,Waveform Type Stepped approximation to a sinewave,Output Connections :(4) IEC 320 C13,(2) IEC Jumpers
Tip conectori:
Interface Port(s) DB-9 RS-232
Baterie:
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof,RBC Quantity 1
Backup time:
Full load: 5.9 minutes (280 Watts)
Timp reincarcare:
5 hour(s)
Protectie:
Surge energy rating 320 Joules,Filtering Full time multi-pole noise filtering : 0.7% IEEE surge let-through : zero clamping response time : meets UL 1449,Data Line Protection RJ-11 2-Way Modem/Fax/DSL splitter with protection (four wire dual lines),RJ45 10/100 Base-T Ethernet protection
Altele:
Emergency Power Off (EPO),Rack Height 1U,Operating Environment 0 - 40 gradeC,Operating Relative Humidity 0 - 95%,Operating Elevation 0-3000 meters,Storage Temperature -15 - 45 �C,Storage Relative Humidity 0 - 95%,Storage Elevation 0-15000 meters,Audible noise at 1 meter from surface of unit 38.00 dBA,Online Thermal Dissipation 38.00 BTU/hr
Culoare:
Grey
Alarma:
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Indicatori:
LED status display with On Line : On Battery : Replace Battery and Overload indicators
Dimensiuni (W x D x H mm):
44.00 mm x 432.00 mm x 383.00 mm
