Standarde:
IEEE 802.3, 802.3u, 802.3af CSMA/CD, TCP/IP
Porturi:
LAN Port 1 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
PoE Port 1 10/100M Auto-Negotiation RJ45 port (Auto MDI/MDIX)
LED Indicators
PWR
Altele
Basic Function :
Compatible with IEEE 802.3af compliant PSEs
Delivers power up to 100 meters
Optional 12VDC or 5VDC power supply
Plug-and-Play,
Network Media :
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m),
EIA/TIA-568 100Ω STP (maximum 100m)
Safety & Emission FCC, CE
Dimensiuni:
81x52x24 mm
Alimentare (V/Hz):
2.0W (12VDC) or 3.3W (5VDC)
