Porturi:
8
Standarde:
IEEE 802.3 10BASE-T Ethernet,
IEEE 802.3u 100BASE-TX Fast Ethernet,
IEEE 802.3ab 1000BASE-T Gigabit Ethernet,
ANSI/IEEE 802.3 NWay auto-negotiation,
IEEE 802.3x flow control,
IEEE 802.3az Energy Efficient Ethernet (EEE)
Cu Management
Nu
Buffer (MB):
RAM Buffer 128 KB
LED Indicators
Per port: Link/Activity/Speed,
Per device: Power
Tabela de adrese MAC
MAC address table: 8K
Viteza de transfer:
Switching fabric 16 Gbps,
Data Transfer Rates :
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex),
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex),
Gigabit Ethernet: 2000 Mbps (full duplex)
Caracteristici speciale:
Layer2 Features :
Auto MDI/MDIX crossover for all ports
Store-and-forward switching scheme,
Full/half-duplex for Ethernet/Fast Ethernet speeds
Full-duplex only for Gigabit Ethernet speed,
Jumbo Frames: 9000 Bytes,
Packet Filtering/Forwarding Rates :
Ethernet: 14,880 pps per port,
Fast Ethernet: 148,800 pps per port,
Gigabit Ethernet: 1,488,000 pps per port,
Quality of Service (QoS) :
Supports 802.1p QoS
4 Queues, Strict Mode
Alimentare (V/Hz)
External 5 V/1 A Level �V� Power Adapter
Putere consumata (W):
Standby: 0.55 watts,
Maximum 2.8 watts
Dimensiuni (W x D x H mm):
162 x 102 x 28 mm
MTBF:
2,053,751 hours
