Porturi:
5
Standarde:
IEEE 802.3 10BASE-T Ethernet,
IEEE 802.3u 100BASE-TX Fast Ethernet,
ANSI/IEEE 802.3 NWay auto-negotiation,
IEEE 802.3x flow control,
IEEE 802.1p QoS,
IEEE 802.3az Energy Efficient Ethernet (EEE)
Buffer (MB):
64 KB
LED Indicators
Per port: Link/Activity/Speed/PoE Status,
Per device: Power/PoE Max
Tabela de adrese MAC
2K
Viteza de transfer:
Switching Fabric :64 KB,
Ethernet:
10 Mbps (half duplex)
20 Mbps (full duplex)
Fast Ethernet:
100 Mbps (half duplex)
200 Mbps (full duplex),
Packet Filtering/Forwarding Rates :
Ethernet: 14,880 pps per port
Fast Ethernet: 148,800 pps per port
Caracteristici speciale:
Layer2 Features :
MAC address table: 2K
Auto MDI/MDIX crossover for all ports
Store-and-forward switching scheme
Full/half-duplex for Ethernet/Fast Ethernet speeds,
PoE Features :
802.3af PoE standard (port 1 only)
Up to 15.4 W
Active circuit protection (PoE port disabled if shortcut detected)
CAT 5A PoE pin-out: 1,2,3,6,
Quality of Service (QoS) :
Supports 802.1p QoS
4 Queues, Strict Mode
Alimentare (V/Hz)
External 48 V/0.5 A Level V Power Adapte
Putere consumata (W):
Power On (stand-by) :
DC input: 0.9 W
AC input: 1.8 W,
Maximum (PoE off) :
DC input: 2.05 W
AC input: 2.7 W,
Maximum (PoE on)
DC input: 17.29 W
AC input: 20.2 W)
Dimensiuni (W x D x H mm):
140 x 85 x 28 mm
MTBF:
324,616 hours
