Image Device
1/3" Exview HAD CCD II (ICX672/3AKA)
DSP Device
Effio-E (CXD4127GG,CXD4816GG)
Resolution
Color Mode: 650TVL; B/W Mode:700TVL
Picture Elements
IR Led & IR Range
22pcs ï¿ 5 IR Led; 20M IR Distance
Min. Illumination
0.001 Lux (F2.0)
Lens Furnished
Built-in 4--9mm Manual Zoom Les (2.8--12mm Optional)
TV System
PAL/NTSC
Electronic Shutter
NTSC:1/60~1/100,000, PAL:1/50~1/110,000
S/N Ratio
More than 52dB
Gamma
0.45
Exposure
Auto
Shuter/ AGC
Auto/Manual
White Balance
ATW / User1/User2
Backlight
OFF/ON/BLC/ HLC
Pict Adjust
Mirror/Brightness/Contrast/Sharpness/Hue/Gain
ATR
ON/OFF
Motion Det
OFF/ON(Detect sense/ Area Sel)
Peivacy Masking
OFF/ON (4 Zone)
Day/Nigh
True Day and Night (Auto/ Day / Night / Ext. D&N)
2D-NR
OFF/ON (Y/C level)
Camera ID
OFF/ON
Sync. System
Internal
Video Output
1 Vp-p / 75 Ohms
Power Supply
DC12V±10%
Operation Temperature
Dimension
¢127 x 91 mm
Weight
600g
