Image Device
1/3" SONY
Resolution
540 TVL
Picture Elements
Min Illumination
0.2 Lux /F2.0
TV System
PAL/NTSC
Lens Furnished
6 mm Board Lens (Optional 4mm or 3.6mm Board Lens)
SN/Ratio
More than 48dB
Electronic Shutter
NTSC:1/60~1/100,000, PAL:1/50~1/110,000
Gamma
0.45
White Balance
Auto
Gain COntrol
Auto
Sync. System
Internal
Video Output
1 Vp-p / 75 Ohms
Power Supply
DC12V±10%
Operation Temperature
Dimension
¢110 x 50 mm
Weight
300g
